Black 55ah Deep Cycle Lead Acid Battery 12v Sealed , 16kg Weight
Description:
| Place of Origin: | Guangdong, China (Mainland) | Brand Name: | CHAMPION | Model Number: | 12V55AH |
| Usage: | UPS | Voltage: | 12v | Sealed Type: | Sealed |
| Maintenance Type: | Free | Size: | 229*138*210 | Weight: | 16KG |
| Nominal Capacity: | 50AH | Low self discharge:: | no charge six months storage at room temperature | Safety: | There are no internal relief valve isolation sparks explosion |
| Long life:: | 3-5 years normal use | Vrla Agm battery lead:: | 99.994% purity lead | Color:: | Grey or Black |
| Container Material:: | ABS | Certification:: | UL,CE,ISO9001,ISO14001 | Delivery time :: | 25days |
Applications:
UPS, Broadband, Electric powered vehicles, Electric powered toys, Vacuum cleaners, Medical Equipments, Goof cars and buggies, Wheel chairs, PVs, solar systems, control systems, power systems, wind energy systems, telecommunication /communication systems & etc.
Specifications:
| Noninal Voltage | 12V | |
| Capacity(10HR,25℃) | 55AH | |
| Designed Life | 10 Years | |
| Dimension | Length | 228mm |
| Width | 138mm | |
| Height | 210mm | |
| Total Height | 224mm | |
| Reference Weight | 16kg | |
Charateristics
|
Capacity 25℃ (77℉) To 1.70V/Cell | ||
| 10 hr rate(5.5A) | 55Ah | |
| 5 hr rate(8.8A) | 44Ah | |
| 1 hr rate(33A) | 33Ah | |
| Inner Resistance(fully charged 25℃) | 6.5mΩ | |
| Self-discharge (at 25℃.) : | 3% of the capacity per month | |
| Discharge Temperature | -20~60℃ | |
| Charge Temperature | -10~60℃ | |
| Storage Temperature | -20~60℃ | |
| Cyclic charging voltage (at 25℃) | 14.4~14.9V | |
| initinal current (at 25℃) | 20A | |
| Temperature Compensation | -30mV/℃ | |
| Float Use (at 25℃) | 13.6-13.8V | |
| Temperature Compensation (at 25℃) | -20mV/℃ | |
Competitive Advantage:
• High Reliability and Quality
• Good deep discharge cycle capability
• Excellent Recovery from Deep Discharge
• Longer Service Life
• Living Up to Prevailing Standards
